ETA 2824-1134 Automatic Device Framework

Product Description

Genuine ETA 2824-1134 Automatic Device Framework, Made in Switzerland, brand new — the original factory structural frame for the ETA 2824/2834/2836 automatic movement’s bidirectional winding mechanism. Precisely engineered to support and mount the oscillating weight, pawl, and ratchet components, the Automatic Device Framework holds the entire self-winding system in precise alignment within the movement. An essential replacement part for restoring a damaged or deformed framework during movement service. Original ETA part — the professional’s choice for genuine automatic winding restoration.

Features & Function

• Genuine ETA 2824-1134 — original Swiss-made factory part, brand new, authentic, part number 2824-1134
• Automatic device framework — structural frame that supports and mounts the oscillating weight, pawl, and ratchet components
• Bidirectional winding support — holds the pawl and ratchet mechanism that enables automatic winding from both rotor directions
• Oscillating weight mounting — provides the precise mounting surface for the bidirectional automatic rotor
• Original factory quality — exact structural geometry and dimensional specifications for perfect fit in the ETA 2824/2834/2836 movement

Specifications

Applications

• Replacement of damaged, bent, or deformed Automatic Device Framework in the ETA 2824/2834/2836 movement
• Repair of automatic winding mechanism failures: automatic device not functioning, rotor not spinning freely
• Repair of framework-related issues: framework misalignment causing pawl engagement failure or ratchet malfunction
• Repair of oscillating weight issues: rotor mounting surface damage or bearing seat wear
• Professional movement service, overhaul, and automatic watch restoration

FAQ

Q1: Is this a genuine ETA part?
A: Yes — this is a genuine ETA 2824-1134 Automatic Device Framework, Made in Switzerland, brand new. It is an original factory part from ETA (Swatch Group), the world’s leading movement manufacturer. Not a generic or replica part.

Q2: How do I confirm this part fits my movement?
A: Confirm your movement is an ETA 2824, 2834, or 2836 automatic movement (11.5 lignes). The part number 2824-1134 is the specific Automatic Device Framework for this movement family. Common brand applications include: Omega Seamaster, Longines Master Collection, Tissot PRX, Certina DS, Hamilton Khaki Field, Tudor Black Bay 2824 variant, and many other watches using the ETA 2824 automatic platform.

Q3: What does the Automatic Device Framework do?
A: The Automatic Device Framework (2824-1134) is the structural frame that supports and mounts all components of the automatic winding mechanism. It holds: (1) The oscillating weight (rotor) — the semi-circular weighted component that spins with wrist movement; (2) The pawl — the lever that engages the ratchet to transfer rotation to the mainspring; (3) The ratchet — the wheel that the pawl engages to wind the mainspring. The framework keeps all three components in precise alignment so they can work together. Without the framework, the automatic winding components would have no structural support and the watch cannot wind itself automatically.
