This is a genuine Ronda 505/515 circuit block electronic module, a Swiss-made component for Ronda 505/515 quartz movements. It serves as the core control component, generating precise 32,768Hz quartz oscillation signals to drive the stepper motor for accurate timekeeping. The module is also compatible with 507, 513, and 517 calibers. This product is brand new and original, intended for repairing movements that fail to run due to circuit failure.
Brand：Ronda (Swiss)
Compatible Movements：Ronda 505 / 515 / 507 / 513 / 517 series quartz calibers
Part Number Reference：3612.198.RK / 4000
Origin：Swiss Made
Quality：Genuine original, brand new
Function：Generates and processes time signals for stepper motor
1. Is this circuit module an original Ronda genuine part?
Yes. It is an original Ronda OEM part, not a third-party copy.
2. Which movements is this circuit module compatible with?
It fits Ronda 505 and 515 series quartz movements, and is also compatible with 507, 513, and 517 calibers. The 505 measures 10½ ligne (23.90mm), and the 515 measures 11½ ligne (26.20mm).
3. How do I check if the circuit module is faulty?
Typical symptom: movement not running after battery replacement. Use a multimeter to measure coil resistance—normal range is between a few hundred and two thousand ohms. An “OL” reading (open circuit) or significant deviation indicates a faulty coil. The coil is exposed near the battery clip and can be easily scratched during battery replacement, causing failure.
