This is a genuine detent designed for the ETA 7750 series self-winding chronograph movement, with part number 7750-8660, Article 30, Made in Switzerland. As a critical component of the chronograph mechanism, the detent controls the start, stop, and reset functions of the chronograph module, ensuring precise and reliable button operation.
This product is a genuine ETA part, brand new, and is the ideal choice for replacing worn components during service or repair of the 7750 movement.
| Feature | Description |
|---|---|
| Compatible Movements | ETA 7750 / 7751 / 7753 / 7754 series automatic chronograph |
| Part Number | 7750-8660 |
| Article Number | 30 |
| Part Name | Detent |
| Core Function | Controls chronograph start, stop, and reset functions |
| Material | High-precision hardened steel |
| Origin | Made in Switzerland |
| Product Type | Genuine ETA part |
ETA 7750 Movement Technical Background:
| Parameter | Value |
|---|---|
| Movement Type | Self-winding mechanical chronograph |
| Diameter | 30.00 mm (13 ¼ lines) |
| Thickness | 7.90 mm |
| Jewels | 25 |
| Power Reserve | Approx. 42-46 hours |
| Frequency | 28,800 vph (4 Hz) |
| Chronograph Mechanism | Cam-actuated |
| Functions | Chronograph, date, day display |
| Instruction | Details |
|---|---|
| Primary Use | Core control component of the chronograph module – enables start, stop, and reset functions |
| Normal Operation | Press 2 o‘clock button to start/stop chronograph; press 4 o’clock button to reset |
| Failure Symptoms | Worn detent causes: abnormal chronograph button feel, chronograph malfunction, inaccurate reset |
1. Remove Movement:Open the case back and carefully remove the ETA 7750 movement
2. Remove Chronograph Module:Remove the chronograph module cover to access control components
3. Remove Old Detent:Carefully remove the old detent (7750-8660) – inspect for wear or deformation
4. Cleaning:Clean the detent mounting area and contact surfaces – remove old oil and debris
5. Inspect Related Parts:Inspect the chronograph cam, reset hammer, and other related components for wear
6. Install New Detent:Place the new detent in position – ensure proper engagement with the chronograph cam
7. Test Function:After installation, test chronograph button feel and function in all positions
Important Note: Assembly of the 7750 chronograph module requires specialized expertise – professional installation by a watchmaker is strongly recommended.
| Aspect | Guidance |
|---|---|
| Inspection Period | Inspect the detent for wear or deformation during each movement service |
| Wear Indicators | Signs of wear include: rough chronograph button feel, sluggish start/stop function, inaccurate reset |
| Cleaning Method | Clean with specialized cleaning solution; do not bend or forcibly adjust the detent shape |
| Lubrication | Apply specialized lubricant to contact points – microscopic amount only |
| Replacement Interval | Replace immediately when wear or deformation is visible |
| Service Advice | ETA 7750 movements should be professionally serviced every 3-5 years |
Q1: Is this detent compatible with all ETA 7750 variants?
A: This detent (part 7750-8660, Article 30) is designed for ETA 7750, 7751, 7753, and 7754 series movements. These movements share the same chronograph control architecture, so the part is generally compatible across the series.
Q2: What are the symptoms of a worn or broken detent?
A: Symptoms include: the chronograph start/stop button feels mushy or inconsistent, the chronograph fails to start or stop, the reset function does not return the hands to zero, or the reset is incomplete.
Q3: Can I install this detent myself?
A: This replacement requires movement disassembly and expertise with the 7750‘s cam-actuated chronograph module. If you lack experience, professional installation by a watchmaker is strongly recommended.
Q4: What other parts should I check when replacing the detent?
A: When replacing the detent, inspect the chronograph cam, reset hammer, and jumper spring. Wear is often synchronized across these components.
Q5: Is this a genuine ETA part?
A: Yes, this is a genuine ETA factory part, made in Switzerland, and brand new. It is not an aftermarket or generic replacement.
Q6: What is the power reserve of the ETA 7750?
A: The ETA 7750 has a power reserve of approximately 42-46 hours, depending on chronograph usage.
