Rolex 2235-145 Complete Automatic Device Module

Product Description

This is a complete automatic device module designed for the Rolex Caliber 2235 movement, part number 2235-145. This module contains the reversing wheels, automatic winding train, and other core components that convert wrist motion into mainspring energy. As an integrated modular design, it can be installed or removed as a complete unit, facilitating movement service and repair of the automatic winding function.

Features & Function

• Compatible Movement: Rolex Caliber 2235
• Part Number: 2235-145
• Module Type: Complete automatic winding device
• Core Components: Reversing wheels, automatic train, rotor (if included)
• Design Feature: Integrated modular design for easy removal/installation
• Function: Converts wrist motion into mainspring energy for self-winding

Usage Instructions

• This module is the automatic winding component of the movement; it works automatically during normal wear
• No manual intervention needed – wrist motion powers the mainspring
• If the watch stops, manually wind it before wearing to supplement power

Installation Instructions

1. Remove the movement from the case and detach the rotor (if installed)
2. Align the automatic module with the mounting position on the main plate
3. Ensure the reversing wheels and automatic train mesh correctly
4. Tighten the securing screws according to the torque specifications in the technical manual
5. Install the rotor and test the winding function
6. After installation, check that the rotor rotates smoothly

Important Notes

• The 2235 automatic module is an integrated design that sits on top of the main plate (rather than being embedded inside the movement)
• Ensure all gears are correctly meshed during installation; otherwise, winding failure may occur
• It is recommended to replace the lubricants on the automatic module at the same time
• This is a generic aftermarket part; professional installation by a watchmaker is recommended

Maintenance & Service Guide

• Lubrication: The automatic module requires specialized lubricants; service every 5-7 years
• Common Issue: Reduced winding efficiency – often requires cleaning of the reversing wheels
• Wear Inspection: Check the automatic train gears for wear or deformation
• Reversing Wheels: The 2235 reversing wheels were improved from the older 2135, with larger steel gears for greater locking force

FAQ

Q1: What is the difference between the Caliber 2235 automatic module and those in other movements?
A: Unlike the ETA 2892 where the automatic winding mechanism is embedded inside the movement, the Rolex 2235 automatic module is a complete unit that sits on top of the main plate. This allows for larger transmission gears and more flexible train layout, though it does increase overall thickness.

Q2: Does this module include the rotor?
A: Please confirm with the seller. The “Complete Automatic Device Module” (2235-145) typically includes the automatic train and reversing wheels. The rotor may be sold separately.

Q3: Will this module fit a genuine Rolex Caliber 2235 movement?
A: It is designed for the Rolex 2235 movement. However, as a generic aftermarket part, minor tolerance differences may exist. Professional installation is recommended.

Q4: How can I tell if my automatic module needs replacement?
A: Signs include: (1) reduced or no automatic winding despite normal wear, (2) unusual noise from the rotor, (3) rough or gritty feeling when the rotor spins, or (4) visible wear or damage to the reversing wheels.

Q5: Can I install this module myself?
A: This is an advanced repair. Installation requires movement disassembly, proper lubrication, and technical knowledge. It is strongly recommended to have a professional watchmaker perform the installation.
